AOC 15.6 Inch LED Backlit LCD - E1660Sw Monitor Specifications


Display 15.6 inch LED Backlit LCD Display
Sales Package Monitor, Power Chord, Manual
Backlight LED Backlight
Resolution 1366 x 768 pixels
HD Yes
Screen Resolution Type HD
Model Name e1660Sw
Screen Form Factor Flat

Display Features

HD Standard 720P
Number of Colors 0.262 M Colors
Aspect Ratio 16:09
Contrast Ratio 400:01:00, 11520:01:00 (Dynamic)
Horizontal Viewing Angle 90° (2D)
Vertical Viewing Angle 55° (2D)
Response Time 16 ms
Brightness 200 nits (2D)
Pixel Pitch 0.252 mm
Horizontal Scanning Frequencies 30 - 50 kHz (Analog)
Other Display Features Vertical Frequency: 60 Hz

Audio Features

Inbuilt Speaker No
Speakers No

Power Features

Power Requirement AC 100 - 240 V, 50/60 Hz
Power Consumption 10 W (Operational), 0.5 W (Standby)

Touchscreen Features

Touchscreen Support No




Height with stand 110 mm
Height without stand 470.8 mm
Depth with stand 323 mm
Depth without stand 160.8 mm
Weight without Stand 2.4 kg
Width Without Stand 373.8 mm
Width With Stand 420 mm

Mounting Features

Wall Mounting 100 x 100 mm
Wall Mount Standard VESA Mount

Additional Features

Controls Luminance, Image Setup, Color Temperature, Color Boost, Picture Boost, Extra, Reset, Exit, OSD Setup
System Requirements Windows 7
Other Features Energy Star, Screen, Eco Mode, Hg Free, Net Weight: 1.6 kg, Approvals and Certifications: cTUVus, FCC, CE, EPA, EPEAT Silver, TUV-S, Windows 7, Image Ratio Exchange, Gross Weight: 2.4 kg, I-menu Software

Dimensions With Stand

Width 420 mm
Height 110 mm
Depth 323 mm
