Asus P8B75-M LX PLUS Motherboard

Name: Asus P8B75-M LX PLUS Motherboard
Brand: Asus Motherboards
Availability: InStock
Rating: 4.5 (600 reviews)

Asus P8B75-M LX PLUS Motherboard-thumb-1

Asus P8B75-M LX PLUS Motherboard-thumb-2

Asus P8B75-M LX PLUS Motherboard-thumb-3

Asus P8B75-M LX PLUS Motherboard-thumb-4

Asus P8B75-M LX PLUS Motherboard Share on

Asus Motherboards

₹8999.00

Latest Motherboards

Intel Motherboards

MSI Z370 Tomahawk DDR4 Motherboard

₹21000.00

Zebion Motherboards

Intel DBS2600CW2 Chipset Dual Socket R3 (LGA2011v3) DDR4 RAM Server Motherboard

₹45000.00

Intel Motherboards

Intel Desktop Board DZ77GAL-70K Motherboard

₹17500.00

Intel Motherboards

Asus P8B75-M LX PLUS Motherboard Specifications

In The Box

Sales Package

Motherboard, Sata Cables, Rear I/O Panel and Support CD

General

Brand	Asus
Model ID	P8B75-MLX PLUS

Essentials

Form Factor	Micro-ATX
Socket Type	LGA 1155
Compatible Processors	Intel 2nd Generation Core i3 Processor, Intel 3rd Generation Core i7 Processor, Intel 3rd Generation Core i5 Processor, Intel 3rd Generation Core i3 Processor, Intel 2nd Generation Core i7 Processor, Intel 2nd Generation Core i5 Processor, Intel Pentium Processor, Intel Celeron Processor, Intel Xeon...View More Intel 2nd Generation Core i3 Processor, Intel 3rd Generation Core i7 Processor, Intel 3rd
Chipset	Intel B75
Chipset Manufacturer	Intel

Connectivity

Ethernet Controller	Realtek 8111F-VB-CG
Ethernet Features	1 x Gigabit LAN

Memory

Number of Memory Slots	2 Slots
Memory Configuration	16 DDR3 Dual Channel DIMM
Memory Frequency	2000(O.C.) MHz, 1866(O.C.) MHz, 1600 MHz, 1333 MHz, 2133(O.C.) MHz, 1066 MHz, 2200(O.C.) MHz
ECC Support	Non-ECC
Buffered Memory	Unbuffered

Storage

SATA 3 Gb/s	Intel B75 Chipset
SATA 6 Gb/s	Intel B75 Chipset

Audio

Audio Codec	VIA VT1708S
Audio Channels	8
Audio Features	Jack-detection, Multi-streaming, Front Panel Jack-retasking, Anti-pop Function, High Definition Audio

Graphics

Integrated Graphics card	Yes
Multi GPU Support	Yes, LucidLogix Virtu MVP Technology

Expansion Slots

PCI Slots	1
PCIe x1 Slots, Generation	2, 2.0
PCIe x16 Slots, Generation	3.0/ 2.0, 1

Internal I/o Headers

SATA 3 Gb/s Headers	5
ATX Power Connectors	1 (24 Pin ATX Power Connectors)
SATA 6 Gb/s Headers	1
USB 2.0 Headers	2
USB 3.0 Headers	1
Fan Headers	1 (Processor Fan Headers), 1 (System Fan Headers)
Front Panel Headers	1
Other Connectors	1 x 4-pin ATX 12V Power Connector, 1 x Parallel Port Connector, 1 x System Panel, 1 x DVI-D, 1 x Internal Speaker Connector, 1 x S/PDIF Out Header

Back Panel Ports

USB 2.0 Ports, Controller	4
USB 3.0 Ports, Controller	2
VGA/D Sub Ports	1
Audio I/O Channels	3
RJ-45 Ethernet Jacks	1
PS/2	1

General Features

OS Support	Windows XP and Above
Bundled Software	Anti-virus Software (OEM version)
Support CDs	Drivers, ASUS Utilities, ASUS Update
BIOS	128 MB Flash ROM, AMI BIOS, PnP, DMI 2.0, WfM 2.0, SM BIOS 2.5, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3
Features	ASUS Anti-Surge Protection, Intel SBA Support, Supports DVI with Maximum Resolution 1920 x 1200 at 60 Hz, DMI 2.0, WOL by PME, PXE, WfM 2.0, EPU, Supports RGB with Maximum Resolution 2048 x 1536 at 75 Hz, WOR by PME
Advanced Features	Windows 8 Ready Assured Compatibility, GPU Boost, ASUS Exclusive Features: AI Suite II, Ai Charger, ASUS UEFI BIOS EZ Mode Featuring Friendly Graphics User Interface, Network iControl, USB 3.0 Boost, ASUS Quiet Thermal Solution: ASUS Fan Xpert, ASUS EZ DIY: ASUS CrashFree BIOS 3, ASUS EZ Flash 2, AS...View More Windows 8 Ready Assured Compatibility, GPU Boost, ASUS Exclusive Features: AI Suite II, Ai

Dimensions

198 x 244 mm

Disclaimer: Specifications shown may be different from the actual product. We cannot guarantee that the information provided on this page is 100% correct. Please check with the retailer before purchasing.
