Dell 1220 Projector

Dell 1220 Projector Share on

amazon ₹27500.00 Go to store

Dell 1220 Projector Specifications


Brand Dell
Usage Education, Business
Model Name 1220
Projection Ratio 1.95 - 2.15
Lamp 190 W Osram
Color Black
Device Chipset DLP
Lamp Life 5000 hr
Resolution 800 x 600 pixels
Display Mode SVGA, Component Video VGA Input: 480i/p, 576i/p, 720p (50/60 Hz), 1080i (50/60 Hz), HDMI Input: 480i/p, 576i/p, 720p, 1080p
Projection Distance 47.28 inch to 32.81 ft

Dimensions Without Stand

Weight 2.4 kg
Height 87.6 mm
Width 314.4 mm
Depth 223.5 mm

Display Features

Maximum Projection Size 252.4 inch
Brightness 2700 lm (Maximum)
Zoom Ratio 1.1x
Aspect Ratio '4:3 (Native)
Contrast Ratio 2200:1 Hz
Other Display Features Image Chipset: 0.55 inch, S450 DMD, DarkChip 3, Single Chip DLP (LVDS), BrilliantColor, Auto Sync Upto: UXGA (1600 x 1200), Diagonal Screen Size: 27.5 inch - 252.4 inch, Lamp Life: 6000 hrs (Eco Mode)
Color Support 1.07 Billion Colors
Part Number 1220

Lens Features

Aperture F2.41 - F2.55
Focal Length 21.8 - 24 mm
Focus Mechanism Manual Focus
Other Lens Features Lens Offset Ratio: 115 % 5 %, Zoom: Manual

Audio Features

Audio Type Stereo
Number Of Speakers 1 Speaker
Other Audio Features RMS Speaker
Output Per Speaker 2 W


Hdmi 1 HDMI Port, Version 1.4
Usb 1 Mini USB-B Slave for Firmware Update and Remote Support Port
Audio In 1 x 3.5 mm Stereo Mini Phone Jack (Blue)
Audio Out 1 x 3.5 mm Stereo Mini Phone Jack (Green)
Headphone Jack Yes
Av In RCA Composite Video In
Vga 1 x 15-pin D-sub, 1 x 15-pin D-sub
Other Connectors 1 x Yellow RCA Jack for CVBS Signal (Composite Video), HDMI Input (HDCP Compliant)

Power Features

Power Supply AC 100 - 240 V
Power Consumption 230 W (110 V AC)
Power Consumption - Standby Mode 0.5 W (110 V AC), 0.5 W (220 V AC)
Other Power Features AC Power Input Socket (3-pin - C14 Inlet)

Operating Conditions

Operating Temperature 5 °C - 40 °C
Noise Level 34 dB (Normal)
Humidity Operating Temperature Humidity: 80 % Maximum, Storage Temperature: 0deg;C to 60deg;C, Humidity: 90 % (Maximum)
Other Operating Conditions Noise Output: 31 dB(A) (Eco Mode) Typical

Additional Features

Signal Type Composite Video Input: NTSC (M, 3.58, 4.43), PAL (B, D, G, H, I, M, N, 4.43), SECAM (B, D, G, K, K1, L, 4.25, 4.4)
Keystone Adjustment Manual Keystone Correction Vertical: 40°
Remote Control Yes
Functional Modes Eco Mode, Normal Mode
Security Slot Yes
Mounting Ceiling, Tilt (Front, Rear)
Other Features Uniformity: 85 % Typical (Japan Standard - JBMA), Elevator Feet / Adjustment Wheels: 1 x Front Tilt Adjustment Wheel (Angle of Tilt: -5° - 5°), 2 x Rear Tilt Adjustment Wheel, Security: Kensington Lock Slot, Password Protection Option, Quick Shutdown, 3D-capable, Mounting Capability, Project...View More Uniformity: 85 % Typical (Japan Standard - JBMA), Elevator Feet / Adjustment Wheels: 1 x Front T
