MSI H170A PC MATE Motherboard Specifications
In The Box
| Sales Package | Motherboard, User Manual |
General
| Brand | MSI |
| Model ID | H170A PC MATE |
Essentials
| Form Factor | ATX |
| Socket Type | LGA1151 |
| Chipset | Intel H170 |
| Chipset Manufacturer | Intel |
Connectivity
| Wireless and Bluetooth | x Realtek RTL8111H Gigabit LAN controller |
Memory
| Number of Memory Slots | 4 Slots |
| Memory Configuration | 64 GB DDR4 Dual Channel DIMM |
| Memory Frequency | 2133 MHz |
| ECC Support | ECC |
| Buffered Memory | No |
Storage
| RAID Controller | Intel® H170 Chipset |
Audio
| Audio Codec | 1 x Realtek RTL8111H Gigabit LAN controller |
| Audio Channels | 7.1 |
| Audio Features | Realtek® ALC887 Codec, 7.1-Channel High Definition Audio |
Graphics
| Integrated Graphics card | Only with iGPU-ready CPU |
Internal I/o Headers
| Other Connectors | - 1 x PS/2 mouse port - 1 x PS/2 keyboard port - 1 x VGA port - 1 x DVI-D port - 1 x HDMI™ port - 1 x LAN (RJ45) port - 4 x USB 3.1 Gen1 ports - 2 x USB 3.1 Gen2 ports - 3 x audio jacks, - 1 x 24-pin ATX main power connector - 1 x 8-pin ATX 12V power connector - 6 x SATA 6Gb/s connectors (2 ports re...View More - 1 x PS/2 mouse port - 1 x PS/2 keyboard port - 1 x VGA port - 1 x DVI-D port - 1 x HDM |
