| Frequency Response |
20 to 20000 Hz |
| Polar Pattern |
Unidirectional (Cardioid) |
| Impedance |
Output Impedance: 1200 Ohm |
| Output Level |
Output Level (0 dB is equal to 1 volt per Pascal): Open Circuit Voltage: -56.5 dB (1.5 mV) |
| Output Clipping Level (at 1kHz, THD Lesser than 1%) |
Minus 9 dBV (0.35 V) |
| SPL |
Maximum SPL: 143.5 dB |
| Dynamic Range |
112.5 Db (maximum SPL to A-weighted noise level) |
| Polarity |
Positive pressure on microphone diaphragm produces positive voltage on pins 3 and 4 with respect to pin 1 (ground) |
| Power Requirement |
5 V (pin 2 to pins 3 and 4) |
| Signal-to-Noise Ratio |
63 dB at 94 dB SPL (IEC 651) |
