VPN | VPN Pass-Through: PPTP, L2TP, IPSec Pass-through |
Certification | CE, FCC, RCM, RoHS |
Other Features | Antenna Type: Three Detachable Dual Band External Antennas, Transmit Power: Less than 20 dBm (EIRP), Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics, Operating Modes: ADSL Modem Router, Wireless Router, Port Forwarding: Virtual server, Port Triggering, DMZ, AL...View More Antenna Type: Three Detachable Dual Band External Antennas, Transmit Power: Less than 20 d |
USB | USB 2.0 |
Number of USB Ports | 2 |
LAN | RJ-45 |
WAN | RJ-45 |
Antennae | External |
Antennae Capacity | 3 x 2 dBi for 2.4 GHz and 3 x 3 dBi for 5 GHz |
Number of Antennae | 3 |
Number of LAN ports | 3 |
Number of WAN ports | 1 |
Depth | 160 mm |
Width | 229 mm |
Height | 37 mm |
Type | Wireless With Modem |
Brand | TP-LINK |
Model | AC1750 Wireless Dual Band Gigabit ADSL2+ Modem Router |
Controls | Power On/Off Button, Wi-Fi On/Off Button, WPS Button, Reset Button |
In The Box | ROUTER |
Part Number | Archer D7 |
Frequency | 5 GHz |
Temperature | Operating Temperature: 0DegC - 40DegC, Storage Temperature: -40DegC - 70DegC degree C |
Operating Humidity | Operating Humidity: 10 % - 90 % Non-condensing, Storage Humidity: 5 % - 90 % Non-condensing |
Power Supply | External Power Supply: 12 V DC / 2.5 A |
Firewall | Wireless MAC Filtering, Network Address Translation (NAT), Denial of Service (DoS), MAC / IP / URL Filtering, SYN Flooding, SPI |
Encryption | 64/128-bit WEP, WPA-PSK/WPA2-PSK, WPA/WPA2 |
Other Security Features | DHCP - Server, Client, DHCP Client List, Address Reservation, DHCP Relay, Quality of Service - ATM QoS, Traffic Control (IP QoS), Guest Network Access, Parental Control, Access Control, Ping of Death, IP/MAC Binding |
Standard IEEE | IEEE 802.3, IEEE 802.11a, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.3u, IEEE 802.3ab, IEEE 802.11ac |
LAN/WAN | 10/100/1000 Mbps |
Wireless Speed | 1750 Mbps |
Operating System | Vista, 8 or Mac OS or Linux-based, Windows: XP, 7 |
