APC BR1500G-IN 1500 VA UPS Specifications
Environmental Features
| Maximum Operating Temperature |
40 degree C |
| Minimum Operating Temperature |
0 degree C |
General
| Brand |
APC |
| Cold Start |
Yes |
| Type |
Line-interactive |
| Model Number |
BR1500G-IN |
| Overload Protection |
Yes |
| Form Factor |
Tower Model |
Convenience Features
| Low Battery Indicator |
Yes |
| Serial Port |
Yes |
| Display Type |
Control panel Multi-function LCD status and control consol |
| Audible Indicator Functions |
Audible Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Digital Display |
Yes |
Battery Features
| Replacement Battery |
Yes |
| Battery Capacity |
12V/9AH -2NOS. |
| Half Load Runtime |
15 min |
| Number of Batteries |
2 |
| Hot-swappable Battery |
Yes |
| Battery Type |
VRLA SMF |
Dimensions
| Cord Length |
1.2 m |
| Weight |
8 kg |
| Height |
30 cm |
| Width |
23 cm |
| Depth |
38 cm |
Input Features
| Input Frequency |
47 to 53 Hz |
| Input Voltage |
230 V |
| Other Input Features |
Cord Length 1.52 meters, Input voltage range for main operations 160 - 280 V |
Output Features
| Output Power Wattage |
865 W |
| Efficiency |
85 % |
| Transfer Time |
4 ms |
| Output Voltage |
230 V |
| Number of Outlet Plugs |
6 |
| Surge Protection |
Data Line Protection Analog phone line for phone/fax/modem/DSL (RJ-11 connector), Network line - 10/100/1000 Base-T Ethernet (RJ-45 connector) |
| Output Waveform |
Stepped Approximation To A Sinewave |
| Output Frequency |
50 +/-3Hz |
