| Dimension (W x D x H) |
Factory configuration:Approx. 463 x 394 x 291mmPaper installed (A4 / LTR):Approx. 463 x 459 x 291mmOutput / ADF trays extended:Approx. 463 x 607 x 329mm |
| Modem Speed |
maximum 33.6kbps (Automatic fall back) |
| Power |
AC 100 - 240V 50 / 60Hz |
| Scanner Type |
Flatbed & ADF |
| Power Consumption |
Standby (scanning lamp is off)USB connection to PC:Approx. 0.9WOFF:Approx. 0.2WCopying*11 (USB connection to PC)::Approx. 25W |
| Protocol |
SNMP (Standard MIB), TCP / IP |
| Operation Panel |
LCD (3.5-inch / 8.8cm TFT color/ Touch)Language: |
| Wireless LAN |
Network Type::IEEE802.11n / IEEE802.11g / IEEE802.11bFrequency Band::2.4GHzChannel::1 - 13Range::indoor 50m (depends on the transmission speed and conditions)Security::WEP64 / 128bit, WPA-PSK (TKIP / AES), WPA2-PSK (TKIP / AES) |
| Compatible Media |
Size::A6, A4, A5, B5, Letter, Legal, Oficio, B-Oficio, M-Oficio, Foolscap, Legal (India), Executive, 4 x 6"", 5 x 7""Type::Plain PaperPhoto Paper Plus Glossy II (PP-201)Photo Paper Plus semi-Gloss (SG-201)Glossy Photo Paper ""Everyday Use"" (GP-508)Matte Photo Paper (MP-101)Photo Paper Pro Luster (LU-101) |
| Scanning Method |
CIS (Contact Image Sensor) \xC3\x97 2 (2-sided) |
| Image Quality |
2 positions (Standard, High) |
| Apple AirPrint |
Available |
| Fax resolution |
Black::8pels/mm x 3.85lines/mm (Standard)8pels/mm x 7.7lines/mm (Fine)300 x 300dpi (Extra Fine)Colour::200 x 200dpi |
| Based on ISO / IEC 24734. |
Approx. 15.5ipmDocument: Colour: |
| Weight |
Approx. 11.4kg |
| Density Adjustment |
9 positions, Auto intensity (AE copy) |
| Maximum Printing Resolution |
600 (horizontal) x 1200 (vertical) dpi |
| Paper Output |
Approx. 75 pages (A4, LTR, LGL) |
| Printable Width |
Up to 203.2mm (8-inch) |
| Google Cloud Print |
Available |
| ADF |
A4 / Letter = 50, Legal = 10, Others = 1Auto 2-sided |
| Printable Area |
Bordered Printing::Top margin: 3mm, Bottom margin: 5mm, Left / Right margin: each 3.4mm (Letter, Legal: Left: 6.4mm, Right: 6.3mm)Bordered Auto Duplex Printing::Top margin: 3mm, Bottom margin: 5mm, Left / Right margin: each 3.4mm (Letter, Legal: Left: 6.4mm, Right: 6.3mm) |
| Interface |
USB flash memoryUSB B Port |
| Scanning Bit Depth (Input / Output) |
Grayscale::16bit / 8bitColour::48bit / 24bit (RGB each 16bit / 8bit) |
| Print Head / Ink |
Type::Individual Ink CartridgesNumber of Nozzles::Total 4,352 nozzlesInk Cartridge:: PGI-2700 (Cyan, Magenta, Yellow, Black)Optional: PGI-2700XL (Cyan, Magenta, Yellow, Black) |
| Paper Handling (Cassette1: Upper)(Maximum Number) |
4 x 6"" = 20, A4 = 10High Resolution Paper (HR-101N) |
| Storage Environment |
Temperature: 0 - 40\xC2\xB0CHumidity: 5 - 95% RH (no dew condensation) |
| Maximum Document Size |
A4, Letter (216 x 297mm)ADF,A4, Letter (216 x 297mm) |
| Acoustic Noise (PC Print) |
Document (A4, B / W, Default)*10:Approx. 56dB(A) |
| Duty Cycle |
up to 30,000 pages/month |
| Support Media for-Auto 2-sided Printing |
A4, Letter |
| Type |
Desktop Transceiver (Super G3 / Color Communication) |
| Black / Colour |
B / W transmission only |
| Recommended Printing Area |
Top Margin::45.8mmBottom Margin::36.8mm |
| Duplex Scanning |
Available (Single pass 2-sided scan) |
| Optical Resolution *4 |
1200 x 1200dpi |
| Paper Size |
A4, A5, B5, Letter, Legal, Oficio, B-Oficio*, M-Oficio, Foolscap, Legal (India), Executive, 4 x 6"", 5 x 7"", 8 x 10"", Envelopes (DL, COM10, C5, Monarch)Custom size [cassette (upper)]: width 89 - 216.0mm, length 127 - 355.6mm, [cassette (lower)]: width 210 - 216.0mm, length 279.4 - 355.6mm)*Not supported for Mac |
| Paper Weight |
Cassette1 (Upper)::Plain Paper: 64-105 g/m2,Canon specialty paper: max paper weight: approx. 275g/m2(Photo Paper Plus Glossy II PP-201) |
| Selectable Resolution *5 |
25 - 19200dpi |
| Scanning Speed *6 *15 |
Approx. 16.0ipmDocument (ADF): B / WscESAT30secA / Simplex |
| Ink End Sensor |
Electrical pulse detect + Dot count |
| Print Head Alignment |
Auto / Manual |
| Copy Speed *9Based on ISO / IEC 29183. |
sFCOT / Simplex:Approx. 11secs.Document (ADF): Colour:ESAT / Simplex:Approx. 11.5ipm\ Document (ADF): B / WESAT / Simplex:Approx. 22.0ipmDocument (ADF): ColourESAT / Duplex:Approx. 6.0ipmDocument (ADF): B / WESAT / Duplex:Approx. 10.0ipmMultiple CopyBlack / Colour::max. 99 pages |
| Applicable Line |
PSTN (Public Switched Telephone Network) |
| Transmission Speed *8 |
Black::Approx. 3secs. (33.6kbps)Colour::Approx. 1min. (33.6kbps) |
| Print Size |
A4, Letter, Legal |
| Scanning Width |
208mm (A4), 214mm (Letter) |
| Compression |
Black::MH, MR, MMRColour::JPEG |
| Gradation |
Black::256 levelsColour::24bit Full color (RGB each 8bit) |
| ECM (Error Correction Mode) |
ITU-T T.30 compatible |
| Automatic Dialing |
max. 99 locations |
| Transmission / Reception Memory *9 |
approx. 250 pages |
| PC FAX |
Windows:AvailableMac:Available |
| Destination Number |
1 location |
| Wired LAN |
Network Type::IEEE802.3u (100BASE-TX) / IEEE802.3 (10BASE-T)Data Rate::10M / 100Mbps (auto switchable) |
| Layout |
1-up (bordered only):Letter, A4, 4 x 6"", 5 x 7"", 8 x 10"", A5, B5, Legal, A6, Oficio, M-Oficio, Foolscap\xE3\x80\x81Legal (India), Executive, Envelopes (DL, COM10, C5, Monarch)Custom size [cassette (upper)]: width 89 - 216.0mm, length 127 - 355.6mm, [cassette (lower)]: width 210 - 216.0mm, length 279.4 - 355.6mm)Print Quality*12:Standard / High,1-up (bordered only):Letter, A4, 4 x 6"", 5 x 7"", 8 x 10"",A5, B5, Legal, Envelopes (DL, COM10)Print Quality*13:Standard / High,Letter, A4, 4 x 6"", 5 |
| Microsoft Mobile Print |
Available |
| PIXMA / MAXIFY Cloud Link |
from smartphone or tablet::Availablefrom printer::Available |
| Environment |
Regulation::RoHS (EU, China)*, WEEE (EU)**To be fixedEco-Label::Energy Star**To be fixed |
| Direct connection (Wireless LAN) |
Available |
| Canon PRINT Inkjet / SELPHY(for iOS / for Android)Canon Easy-PhotoPrint(for Windows RT) |
Available |
| Mopria |
Available |
| USB Flash Memory |
JPEG and TIFF (Exif-compliant) taken by DCF (Ver.1.0 / 2.0) compliant digital cameras. (Exif ver2.2 / 2.21 / 2.3 compliant) |
| Operating Environment *12 |
Temperature: 5 - 35\xC2\xB0CHumidity: 10 - 90% RH (no dew condensation) |
| Recommended Environment *13 |
Temperature: 15 - 30\xC2\xB0CHumidity: 10 - 80% RH (no dew condensation) |
| Quiet mode |
Available |
| Typical Electricity Consumption |
(TEC)*14::Approx. 0.2kWh |
