Detailed Specifications
Technical Specifications
| Input Voltage |
230 V |
| Frequency Range |
47-270 V AC |
| Operating Voltage |
150-270 V AC |
| Ultra Violet Lamp |
8 Watts (1Nos.) |
| Solenoid Valve |
12 V DC (1 Nos.) |
| Power Rating |
20 Watts |
| Fuse |
In-line Slow Blow 2.5 Amps |
Installation
| Registration |
After Purchasing the product Call on3988-3333 and register your address where installation will be done. |
| Charges |
Installation is free. |
| Timeline |
Installation is done within 24 to 48 Hours. |
Visual Indications
| Power On |
ON PCB board Green LED |
| Status Indication |
LCD Display |
| Recommended Output water Flow Rate |
2 Litres / Minute (Max.) |
| Cartridge Life |
3300 Litres |
| UV Lamp Life (As per Lamp manufacturer specifications) |
5000 burning hours |
| Input Water Temperature |
5 Degree C (minimum) and 50 Degree C (maximum) |
| Installation |
Wall Mounted |
| Optional |
Stand for table top installation |
Dimensions
| Weight |
4.95 Kg |
| Dimensions(WXDXH) in mm |
208X228X430 |
Dimension
| Height |
43 cm |
| Length |
22.8 cm |
| Width |
20.8 cm |
| Weight |
4.95 kg |
General
| Model Name |
Aquasure Elite UV |
| Model |
Aquasure Elite |
| Brand |
Eureka Forbes |
| Water Type |
Soft Water |
| Technology |
UV |
| Type |
Water Purifier |
Disclaimer: Specifications shown may be different from the actual product. We cannot guarantee that the information provided on this page is 100% correct. Please check with the retailer before purchasing.
