| Other Features | ADSL standard: ADSL2 +: G.992.5 (G.dmt.bitplus) Annex A / Annex M; ADSL2: G.992.3 (G.dmt.bis) Annex A / Annex L / Annex M; ADSL: G.992.1 (G.dmt ) Annex A, G.994.1 (G.hs), compatible with ANSI T1.413 Issue 2, ITU-T, WLAN: supports WLAN button and WPS2.0; supports WPA-PSK, WPA2-PSK authentication mode...View More ADSL standard: ADSL2 +: G.992.5 (G.dmt.bitplus) Annex A / Annex M; ADSL2: G.992.3 (G.dmt.b |
| USB | 0 |
| Number of USB Ports | 0 |
| LAN | RJ-45 |
| WAN | RJ-11 |
| Antennae | External |
| Antennae Capacity | 3Dbi Powerful Dual External Antenna |
| Number of Antennae | 2 |
| Number of LAN ports | 4 |
| Number of WAN ports | 1 |
| Weight | 360 g |
| Depth | 296 mm |
| Width | 214 mm |
| Height | 60 mm |
| Supported Software | Internet Explorer 7, Safari 4, Firefox 3 and Above |
| Color | White |
| Series | Wireless ADSL Modem Router |
| Type | Wireless With Modem |
| Brand | Huawei |
| Model | HG532D |
| Controls | WPS Button, Power Button |
| In The Box | Modem Router, Power Adapter, Lan Cable, Adsl Cable & Connector |
| Operating Range | 300 m |
| Frequency Band | Single Band |
| Frequency | 2.4 GHz |
| Temperature | 0°C to 40°C degree C |
| Operating Humidity | 5% ~ 95% ( non-condensing ) |
| Power Consumption | 6 W |
| Power Supply | Power supply: 12V DC, 0.5A, Power consumption: |
| Other Security Features | support Firewall; support MAC, IP, URL address filtering, APP port filtering; supports ACL and DMZ; support PAP, CHAP, PAP/CHAP multiple authentication methods; support DoS attack protection |
| Standard IEEE | IEEE 802.11b/g/n |
| DSL Modem Speed | 300 Mbps |
| LAN/WAN | 10/100 Mbps |
| Wireless Speed | 300 Mbps |
| Operating System | Windows: XP SP3, Vista SP1, 7, Mac OS X 10.5.8 and Above |
