Luminous Pro 2250Va/24V Inverter Specifications
Convenience Features
| Display Type | LED |
| Emergency Power Off | Yes |
| Protection Against | Overload, Deep Discharge, Short-circuit, Reverse Polarity & Input Mains Protection Thtough MCB |
| Other Convenience Features | Smart Charge Technology that can charge battery quicker than normal long-up UPS |
| Cooling System | Fan Systems |
| USB Charging Port | No |
Environmental Features
| Other Environmental Features | Capable of running heavy loads such as laser printers, photo-copies, scanners etc. |
| Storage Temperature | 0-45 C (32-113 F) |
| Operating Temperature | 0-45 C (32-113 F) |
General
| Brand | Luminous |
| Type | Square Wave Inverter |
| Battery Included | No |
| Mode Type | Automatic |
| Model Name | Pro UPS 2250 |
| Model Number | PRO UPS S/Q WAVE 2250/24V |
| Back Up Time | 8 hrs |
| Solar Power Compatible | No |
| Load Options | 5 CFL, 5 FAN, 4 TUBE LIGHT, 2 TELEVISION 1 COMPUTER |
| Technology Used | square wave |
| Fixture Type | Table Top |
| Switch Type | POWER ACTIV SWITCH |
Battery Features
| Battery Boost Voltage | 14+/-.05 |
| Recharge Time | 10-12 Hrs |
| Replacement Battery | Yes |
| Number of Batteries | 2 |
| Compatible Battery Make | Sukam, Luminous, Exide, Okaya, Microtek, Local |
| Other Battery Features | 3 Mode Battery Charger |
| Compatible Battery Types | Lead Acid, Tubular, Flat Plate, SMF, VRLA |
| Battery Charging Current | 20 amp |
Additional Features
| Corrosion Resistant | Yes |
| Other Features | 95 Volts Charge battery with full current even at 95 volts, 3 mode battery charger, Can run printer/photo-copier |
Input Features
| Input Frequency | 45-55 Hz |
| Input Voltage | 90+/-5V |
| Other Input Features | 100-290V |
| High Cut Input Voltage | 290 |
| High Cut Recovery Input Voltage | 280+/-10V |
Dimensions
| Weight | 19.3 kg |
| Height | 15 cm |
| Width | 33.8 cm |
| Depth | 40 cm |
Output Features
| Efficiency | 94.1 % |
| Output Voltage | 220V AC |
| Surge Rating | 2000 VA |
| Output Frequency | 50+/-2.5Hz |
| Output Power | 1600 W |
| Change Over Time | 8 ms |
| Overload Rating | >100% |
| Change Over Voltage | 90v |
| Other Output Features | Short Circuit Protaction, Overload Protaction |
