Intel 3.06 GHz LGA 1156 Core I3-540 Processor Specifications
General Features
| Brand | Intel |
| Series | Core i3-500 Desktop |
| Turbo Boost | No |
| Type | Desktop |
| Virtualisation | Yes |
| Model ID | Core i3-540 |
| Socket Type | LGA 1156 |
| Threading/Transport | Yes |
| Architecture | 64-bit |
| Instruction Sets | SSE4.2 |
General
| Voltage Range | 0.6500 V - 1.4000 V |
| Speed | 3.06 GHz |
| Number of Cores | 2 Cores |
| Intel Smart Cache | 4 MB |
| Manufacturing Process | 32 nm |
| Maximum Thermal Design Power [TDP] | 73 W |
| Bus Speed | 2.5 GT/s |
| Number of Threads | 4 Threads |
| Bus-Core Ratio | 23 |
Memory
| Maximum Memory Bandwidth | 21 GB/s |
| Maximum Memory Size Supported | 16 GB |
| Memory Channels Supported | 2 Channel |
| Memory Type Supported | DDR3-1066, DDR3-1333 |
Graphics
| Other Graphics Features | Intel Flexible Display Interface (Intel FDI), Intel Clear Video HD technology, Dual Display Capable |
| Base Frequency | 733 MHz |
| Integrated Graphics | Yes |
Expansion Slots
| PCI Slots | 1 |
| PCI Configurations | 1 (x16), 2 (x8) |
| PCIe x8 Slots, Generation | 2 |
| PCIe x16 Slots, Generation | 1 |
