IBall ADSL2+ Router Specifications
Additional Features
| Certification |
CE Certification, FCC Certification, RoHS Certification |
| Other Features |
Switching Features: IGMP snooping / Port VLAN / Tag VLAN, Complies with ADSL protocols (ADSL / ADSL2 / ADSL2), Remote management control, Build-in DHCP Server, Web Based management control |
Connectivity
| Number of USB Ports |
1 |
| LAN |
RJ-45 |
| WAN |
RJ-11 |
| Antennae |
Internal |
| Number of LAN ports |
1 |
| Number of WAN ports |
1 |
Dimensions
| Depth |
120 mm |
| Width |
174 mm |
| Height |
29 mm |
General
| Color |
Black |
| Type |
Wired With Modem |
| Brand |
Iball |
| Model |
ADSL2 Router, 1 Ethernet Port & 1 USB Port |
| Part Number |
iB-LR6111A |
| LED Indicator |
Power, ADSL, ACT, LAN, USB |
| Installation Features |
UPnP Server |
Operating Conditions
| Temperature |
Operating: 0DegC - 40DegC, Storage: - 40DegC - 70DegC degree C |
| Operating Humidity |
Operating: 10 % - 90 % Non-condensing, Storing: 5 % - 95 % Non-condensing |
Security
| Firewall |
Stateful Packet Inspection (SPI), NAT, Packet Filter |
| Other Security Features |
URL, MAC, IP Filtering, Application Filtering |
Supported Protocols
| Standard IEEE |
IEEE 802.3, IEEE 802.3u |
Speed
| DSL Modem Speed |
24 Mbps |
| LAN/WAN |
10/100 |
