Seagate Pipeline HD (ST3500312CS) 500GB Desktop Internal Hard Drive Specifications
In The Box
| Sales Package | Internal Hard Drive |
General
| Brand | Seagate |
| Series | Pipeline |
| Model ID | pipeline HD 500gb |
Drive Configuration
| Form Factor | 3.5 inch |
| Device | Desktop |
| Device Type | 3.5 inch HDD |
| Drive Capacity | 500 GB |
| Spin Speed | 5900 rpm |
| Interface | SATA |
| Reliability | 50000 (Load/Unload Cycles) |
| Cache Memory | 8 MB |
| I/O Transfer Rate | 2400 Mbps |
| Average Seek Time | 14.0 ms (Read), 15.0 ms (Write) |
| Non-recoverable Read Error | 1 per 10^14 |
Power
| Idle | 3 W |
| Power Consumption | 0.7 W (Standby/Sleep) |
| Standard Input Voltage | 12 V DC |
| Maximum Start Current | 2 A |
Dimensions
| Dimensions | 101.8 x 20.2 x 146.9 mm |
| Weight | 420 g |
Operating Conditions
| Operating Temperature | 0DegC to 75DegC |
| Non-Operating Humidity | 5 % - 95 % |
| Non-Operating Temperature | -40DegC to 70DegC |
| Shock Tolerance | 70 G for 2 ms (Operating), 350 G for 2 ms (Non-Operating) |
| Operating Humidity | 5 % - 90 % |
